Safety
Stickers & Signs
Durable safety stickers and warning signs to ISO 3864, ANSI Z535, GHS/CLP, and EN ISO 7010 standards — on polyester, polypropylene, destructible vinyl, reflective PET, and aluminium foil substrates — in prohibition, warning, mandatory, and safe-condition signal colours — with custom pictogram artwork, bilingual text, tamper-evident and sequential-numbered constructions — engineered for machinery guarding, electrical panels, chemical containers, process plant, and OEM equipment across industrial and export applications.
A safety sticker that fades or peels is a compliance liability, not a safety measure.
A warning label on a machine guard, an electrical panel, or a chemical container is a permanent part of the equipment's safety system. It must remain legible for the operating life of the equipment — surviving every cleaning cycle, fluid splash, UV exposure, and temperature excursion the environment delivers. PET with UV overlaminate for general industrial and outdoor environments. Polyimide for high-temperature surfaces. Chemical-resistant laminate for solvent and fuel exposure. Adhesive matched to the specific application surface.
Standards compliance is not a style option — it's what makes the label legally valid.
ISO 3864, ANSI Z535, GHS/CLP, and EN ISO 7010 are not interchangeable. Each standard specifies symbol geometry, signal colour values, panel proportions, and minimum sizes that determine whether the label is recognised under the relevant regulation. We verify pictograms, signal colours, and panel construction against the applicable standard before production. CE-marked machinery for export is supplied with compliance documentation confirming the standard applied.
Replacing a damaged safety label is a maintenance task. Not replacing it is an incident waiting to happen.
Facilities with high equipment turnover, aggressive cleaning regimes, or outdoor exposure need a reliable replenishment stock of standard safety stickers. Pre-collated sets matched to machine type, asset number, or plant area reduce the search time between identifying a damaged label and replacing it. Sequential numbering and barcode printing support asset-linked compliance records and inspection sticker programmes where regulatory audit is a regular requirement.
Safety Sign Categories
The Right Colour for the Right Hazard
ISO 3864 and EN ISO 7010 define four safety sign categories, each with a specific signal colour and geometric form. Prohibition in red. Warning in yellow. Mandatory in blue. Safe condition in green. Tell us the hazard or required action and we'll specify the correct category, symbol, and construction.
Prohibition
Red · ISO 3864 / EN ISO 7010
Circular red border with diagonal bar over a black pictogram on white. Prohibits a specific action — no smoking, no entry, no unauthorised access.
Typical Use
Restricted areas, no-smoking zones, fire door keep-shut labels.
Warning
Yellow · ISO 3864 / ANSI Z535
Yellow triangle with black border and black pictogram. Indicates a hazard that could cause injury or damage if precautions are not taken.
Typical Use
Machinery pinch points, electrical hazards, chemical exposure warnings.
Mandatory
Blue · ISO 3864 / EN ISO 7010
Blue circle with white pictogram. Instructs a specific action that must be taken — wear PPE, use handrail, lock out before service.
Typical Use
PPE requirements, lockout/tagout, mandatory action zones.
Safe Condition
Green · ISO 3864 / EN ISO 7010
Green rectangle or square with white pictogram. Indicates a safe route, emergency exit, first aid equipment, or safety facility location.
Typical Use
Emergency exits, first aid kits, eyewash stations, muster points.
Supply Options
Standard vs Custom vs Full Set
Standard library stickers for common hazards and replenishment stock. Custom artwork for non-standard hazards, OEM machinery, and chemical containers. Pre-collated equipment safety sets for CE marking programmes, commissioning, and plant turnaround — all constructions available from the same manufacturing platform.
| Property | Standard Safety Sticker | Custom Safety Sticker | Full Equipment Safety Set |
|---|---|---|---|
| Best For | Single hazard, fixed equipment surface, standard symbol | Non-standard hazard, specific pictogram, exact size or shape | New machinery CE marking, process plant safety audit, full equipment sign-off |
| Artwork Source | Library pictogram — ISO / ANSI / GHS symbol bank | Customer-supplied or created-to-specification artwork | Mixed library and custom artwork, pre-collated per machine or plant area |
| Size Range | 25 mm to 200 mm — standard increments | Any size — matched to available surface and viewing distance | Mixed sizes supplied collated per equipment unit or area |
| Supply Format | Roll, sheet, or die-cut singles | Die-cut to drawing; roll or sheet to application method | Pre-collated packs per machine serial number or plant area |
| Lead Time | From stock or short-run from 3–5 days | Artwork approval + production — typically 5–10 working days | Per project scope — quotation includes schedule |
| Typical Application | Replacement labels, site replenishment stock, standard hazard marking | OEM machinery marking, chemical containers, non-standard hazards | CE marking programmes, plant turnaround, new equipment commissioning |
Construction
Engineered Layer by Layer
Eight material and processing layers — from liner and die-cut geometry through adhesive, tamper-evident construction, face stock, white base ink, signal colour and pictogram print, and UV overlaminate — configured to hold pictogram legibility, signal colour accuracy, and substrate adhesion across the rated equipment service life.
L-01
UV Overlaminate / Hard Coat
Gloss / Matte / Anti-Graffiti — Chemical & Abrasion Resistant
L-02
Safety Symbol Print Layer
Pictograms, Signal Words, GHS Icons, Hazard Diamonds
L-03
Signal Colour Background
Red / Orange / Yellow / Green / Blue — Spot or Process
L-04
White Opaque Base Ink
Full-Coverage Foundation on Translucent Film
L-05
Face Stock / Substrate
PET / PP / Polyimide / Vinyl / Aluminium
L-06
Tamper-Evident Layer (Optional)
Void / Destructible / Consecutive Numbering
L-07
Pressure-Sensitive Adhesive
Permanent / Removable / High-Tack / Aggressive
L-08
Liner & Die-Cut Geometry
Kiss-Cut / Die-Cut / Sheet / Fanfold to Drawing
Technical Parameters
Print & Substrate Specs
Standard performance parameters for our safety sticker range. All values configurable to your compliance standard, application surface, chemical exposure environment, and required service life.
Materials & Configuration
Built to Your Safety Specification
Face stock grade, signal colour system, pictogram standard, tamper-evident construction, adhesive system, and supply format — every variable configured precisely to your compliance requirement, application surface, operating environment, and installation method.
Face Stock / Substrate
Signal Colour Options
Compliance & Symbol Sets
Supply & Cut Format
Capabilities
Feature & Build Variants
Substrate, signal colour, pictogram standard, tamper-evident construction, adhesive system, and supply format — every variable configured to your compliance requirement, application surface, and installation method.
Production Capability
Built for Serious Production
ISO 3864, ANSI Z535 & GHS/CLP — Compliance-Ready Artwork
Safety stickers produced against published international safety sign standards. Pictograms, signal words, supplementary text, and panel proportions verified against ISO 3864-1/-2, ANSI Z535.4, and GHS/CLP hazard communication requirements before production print. Custom symbol artwork supplied by the customer or created to specification. CE-marked machinery and exported equipment supplied with documentation confirming standard applied.
Durable for the Operating Life of the Equipment It Marks
A safety sticker on a machine guard has one job: remain legible and adhered for the service life of the machine. PET with UV overlaminate for general industrial and outdoor environments. Polyimide for high-temperature surfaces. Destructible vinyl for tamper-evident applications. Adhesive system matched to the application surface — painted steel, powder coat, anodised aluminium, polypropylene, and textured engineering plastics. Chemical resistance verified against the exposure environment: fuels, hydraulic fluid, cutting oils, solvents, and cleaning agents.
Signal Colour Accuracy — Spot & Process Matched
Red, orange, yellow, green, and blue signal colours produced to ISO 3864-1 colorimetric specification or ANSI Z535 standard colour references. Spot colour printing for maximum consistency on production runs. Process-matched CMYK for multi-colour panel constructions with pictograms, hazard diamonds, and signal word panels in a single print pass. Colour accuracy verified on proofing substrate before production.
Tamper-Evident & Sequential — Traceability Built In
Destructible vinyl face stock fractures on removal attempt — evidencing any tampering with a safety label without requiring separate seals. Void PSA leaves a VOID pattern on the application surface on removal. Sequential numbering and barcode printing for asset-linked compliance records, calibration labels, and inspection sticker programmes. All tamper-evident and sequential constructions available in standard safety signal colours with full pictogram and text print capability.
Applications
Equipment & Sectors Served
Wherever a safety sticker must communicate a hazard, a prohibition, a mandatory action, or a safe condition — from machinery guarding and electrical switchgear through chemical containers, process plant, lifting equipment, and OEM exported machinery requiring compliance marking for destination markets.
Industrial Graphics Range
Related Products
Instruction Labels
Multi-panel instruction labels in flat, accordion-fold, and booklet constructions — for machinery operating panels, maintenance schedules, assembly guides, and appliance care labelling.
Industrial Stickers
Heavy-duty adhesive stickers on PET, PP, and polyimide substrates for asset identification, equipment marking, barcode labels, and chemical container labelling.
Vinyl Graphics & Vehicle Wraps
Wide-format printed vinyl graphics in cast, polymeric, and calendered PVC — for fleet vehicle wraps, machinery marking, wall graphics, and site hoardings.
Every Hazard Communicated.
Every Label Compliant.
Share the hazard type, applicable standard, application surface, operating environment, and required quantities — we'll come back with a symbol specification, substrate recommendation, and a detailed manufacturing quote.
