Reflective
Signage & Sign Plates
IRC:67-compliant retroreflective road signs — regulatory, warning, and informatory — manufactured on IS 15058 aluminium substrate with Engineer Grade through Diamond Grade prismatic film, screen-print and digital UV legend, in signal red, yellow, white, green, blue, and fluorescent colours — for highway authority supply, state PWD contracts, municipal road programmes, construction zone signing, and industrial plant traffic control.
A retroreflective sign is a measured performance specification — not a material finish.
IRC:67 and IS 15058 prescribe minimum retroreflectivity values (RA) for each sign class at defined observation and entrance angles. A sign that does not meet the minimum RA value for its class is non-compliant regardless of how reflective it appears visually in daylight. Highway authority sign procurement, NQM audits, and IRC:67 implementation guidelines all require documented retroreflectivity testing before and after installation — not visual inspection. Supplying to the specification means supplying measured, documented retroreflectivity, not just a film that describes itself as reflective.
Sign class, geometry, and colour are all regulatory — deviation creates liability.
IRC:67 defines exact symbol geometry, border width, colour specification, and font for each sign type. A stop sign that is the wrong size, uses an incorrect red, has a border too narrow, or lacks the correct legend typeface is a non-conforming sign — potentially invalid for highway authority handover and a liability in the event of an accident. We manufacture to drawing and specification rather than to visual approximation. Approval drawings, colour swatches matched to IRC:67 colour references, and retroreflectivity test data are produced for each job and are available for authority handover documentation.
Screen-printed legend on retroreflective face — not vinyl, not inkjet on white board.
Vinyl-applied lettering on retroreflective sheeting lifts at edges under UV and thermal cycling within two to four years in tropical road environments. Standard inkjet print on white aluminium boards does not retroreflect the legend at all — only the unpainted surround reflects. Correct legend application is screen-printing directly on the retroreflective face stock in UV-stable inks formulated for outdoor sign use, or digital UV flatbed printing on retroreflective substrate for short-run and variable-data requirements. The legend retroreflects back at the driver because the ink layer is formulated not to block the prismatic cell geometry beneath it.
IRC:67 Sign Classes
Three Sign Classes. One Specification.
Regulatory, Warning, and Informatory signs defined by IRC:67 each carry specific shape, colour, size, retroreflective grade, and legend requirements. Tell us the sign type, road class, and post span — we confirm the correct specification and substrate thickness.
| Property | Regulatory Signs | Warning Signs | Informatory Signs |
|---|---|---|---|
| Sign Class | Mandatory (IRC:67 Series A) | Cautionary (IRC:67 Series B) | Informatory (IRC:67 Series C) |
| Shape | Circle / Octagon | Equilateral Triangle | Rectangle / Square |
| Colour Scheme | Red Border / White BG / Black Symbol | Red Border / Yellow BG / Black Symbol | Blue / Green BG / White Legend |
| Min. Retroreflectivity | High-Intensity (Type III) minimum | High-Intensity (Type III) minimum | Engineer Grade (Type I) acceptable |
| Typical Size (IRC:67) | 600 mm / 900 mm diameter or octagon | 600 mm / 900 mm side triangle | 450 × 600 mm to 1200 × 2400 mm |
| Substrate | 1.0 mm 5052-H32 Aluminium | 0.8 mm / 1.0 mm Aluminium | 0.3 mm / 0.8 mm Aluminium or PET |
Construction
Eight Layers, One Sign Plate
From the sealed aluminium blank through adhesive bond, retroreflective prismatic face film, colour layer, screen-printed or UV-printed legend, and UV-stable overlaminate — each layer is specified for outdoor road service life, not for indoor or short-term use.
L-01
Anti-Graffiti / UV Overlaminate
Clear Gloss or Matte UV-Stable Topcoat
L-02
Screen-Print or UV Legend
Regulatory Symbol, Legend & Border per IRC:67 / IS
L-03
Retroreflective Face Film
Engineer / High-Intensity / Diamond Grade Prismatic
L-04
Colour Base Layer
White, Yellow, Red, Green, Blue, Fluorescent
L-05
Adhesive Bond Layer
Pressure-Sensitive or Structural Adhesive Film
L-06
Aluminium Sign Blank
0.3 mm / 0.8 mm / 1.0 mm / 1.2 mm 5052-H32 Alloy
L-07
Back-Coat / Edge Seal
Polyester or Epoxy Backer, Folded & Sealed Edges
L-08
Mounting Provision
Pre-Punched Holes, Clamp Slot or Channel Frame
Technical Parameters
Sign Plate Specifications
Standard performance and material parameters across our reflective sign plate range. All values grade- and substrate-dependent — specify application road class and service life requirement for full confirmation.
Sign Types & Variants
Every Sign Class. Every Environment.
Regulatory, warning, and informatory signs to IRC:67 — plus industrial and plant signage to IS 9457 and ISO 7010 — manufactured on the same retroreflective aluminium sign plate system.
Regulatory Signs
Warning Signs
Informatory & Guide Signs
Industrial & Site Signs
Capabilities
Feature & Build Variants
Sign class, retroreflective grade, substrate thickness, print method, colour, edge treatment, mounting provision, and supply format — every variable configured to your road authority, industrial, or municipal specification.
Production Capability
Built for Serious Production
IRC:67 & IS 15058 Regulatory Sign Production
Regulatory, warning, and informatory signs manufactured to Indian Roads Congress IRC:67 specifications — correct symbol geometry, border dimensions, colour values, legend font, and retroreflective grade for each sign class. IS 15058 aluminium sign blank dimensions and retroreflectivity test requirements met and documented. Approval drawings, batch test certificates, and photometric reports supplied as standard for highway authority procurement.
Diamond Grade Prismatic — 12-Year Road Service Life
Diamond Grade sealed-lens prismatic retroreflective sheeting on 0.8 mm or 1.0 mm 5052-H32 aluminium substrate, sealed edges, UV-stable overlaminate — rated to twelve years outdoor service life on road-facing vertical surfaces. Retroreflectivity measured per ASTM D4956 Type IV criteria at 0.2° observation and −4° entrance angle before dispatch. Batch retroreflectometer data supplied against each order for highway authority handover documentation.
Screen-Print and Digital UV Legend Matching
Regulatory symbols, legends, borders, and colour fills applied by screen-printing to retroreflective face stock — not vinyl appliqué that lifts at edges or digital print inks that discolour within five years. Colours matched to IRC:67 and IS specification: signal red, signal yellow, white, green, and blue on retroreflective face. Digital UV print available for short-run, variable-data, and full-colour informatory signs beyond screen-print production minimums.
Highway Authority, PWD, and Municipal Supply
Production capacity for road authority sign replacement and new-road supply programmes — blanket purchase orders, scheduled release, documented batch traceability. Sign plates supplied blank or with mounting frame, post clamps, or channel extrusion hardware on request. Part-number continuity and retroreflectivity grade consistency matched across reorders — critical for multi-year maintenance contracts where sign specification cannot drift between supply batches.
Applications
Roads, Sites & Industries Served
Wherever a retroreflective sign is required to perform to a documented standard — from national highway authority programmes through construction zone temporary signing, industrial plant traffic management, and municipal urban road signage replacement.
Reflective & Safety Range
Related Products
Retroreflective Stickers & Marking
Engineer Grade to Diamond Grade retroreflective stickers on aluminium, polyester, and polycarbonate substrates — for vehicle conspicuity marking, hazard chevrons, site boundaries, and industrial plant safety.
Reflective Safety Labels
Retroreflective adhesive labels for equipment, machinery, and site asset identification — in standard and custom shapes, with screen-print or UV-print legend, on flexible PET substrate.
Road Safety Signs
IRC:67-compliant road safety and regulatory sign supply for highway authority and PWD programmes — full range of regulatory, warning, and informatory sign types on aluminium backing.
Every Sign Class.
Every Standard Met.
Share your sign type, road class, retroreflective grade requirement, substrate thickness, and required quantity — we'll confirm the correct IRC:67 specification and supply a detailed manufacturing quote with approval drawings.
