Custom PET & Polycarbonate
Graphic Overlays
Precision-printed polyester (PET) and polycarbonate (PC) graphic overlays — clear, transparent or frosted, with second-surface print and Pantone-matched colour — engineered for long-term durability and exact OEM fit, from a single prototype to full production volume.
Construction
Engineered Layer by Layer
Every graphic overlay is a precision print-and-fabrication stack — each layer contributing to colour fidelity, surface durability, and adhesion performance in the field.
L-01
Graphic Print Layer
Screen / Digital Ink Deposit
L-02
Hard-Coat Surface
Scratch & Chemical Resistance
L-03
Overlay Substrate
Polyester (PET) / Polycarbonate
L-04
Display Window
Clear / Tinted Viewing Area
L-05
Selective Texture
Matte / Gloss / Velvet Zone
L-06
Emboss Profile
Dome / Rim / Pillow (Optional)
L-07
Adhesive System
3M / Tesa / Custom PSA
L-08
Release Liner
Peelable Field-Install Backing
Choosing a Substrate
PET vs Polycarbonate Graphic Overlays
Both are printed on the second surface and hard-coated — the choice comes down to whether the overlay flexes, what it is cleaned with, and how much optical clarity the display window needs.
PET (Polyester) Graphic Overlays
Best for: Membrane switch overlays, keys pressed millions of times, panels cleaned with solvents
Polycarbonate (PC) Graphic Overlays
Best for: Display windows, rigid front panels and fascias, short runs and prototypes
Clear, Transparent & Frosted PET Overlays
Clear PET
Fully transparent film with second-surface print underneath, so graphics are protected beneath the film.
Transparent Windows
Clear display and LED windows left unprinted within an opaque printed overlay.
Frosted PET
Matte diffusing finish that spreads backlighting evenly behind icons and indicators.
Textured / Matte
Anti-glare textured surface for key areas, combinable with gloss windows in one overlay.
Technical Parameters
Print & Material Specs
Standard performance parameters for our graphic overlay assemblies. All values configurable to your application requirements.
Materials & Configuration
Built to Your Substrate
Substrate material, print technology, surface finish, and fabrication details selected to match your operating environment and brand spec.
Substrate Materials
Print Technologies
Surface Finishes
Fabrication Options
Capabilities
Feature & Build Variants
Print, finish, backlight, emboss, and adhesive options — configured precisely to your interface specification and brand standards.
Engineering Supply
Printed and Laminated to Your Artwork and Spec
Artwork to OEM Faceplate
From your vector files or dimensional drawings to a production-ready overlay — matched to Pantone, dimensionally accurate, and adhesive-ready.
Prototype to Volume
Short-run engineering samples for design and fit validation, transitioning seamlessly into full OEM production volume.
Integrated Interface Build
Overlay supplied as a standalone component or as part of a complete membrane switch or HMI assembly — your choice.
Print & Dimension Verified
Colour delta, registration tolerance, adhesion, and dimensional accuracy inspected to OEM acceptance criteria on every batch.
Applications
Industries Served
Manufactured for interface-intensive industrial and technical applications where colour accuracy, surface durability, and dimensional precision are non-negotiable.
Ready to Build Your
Overlay Solution?
Share your artwork files, dimensions, or Pantone references — our team will respond with a detailed manufacturing quote.
