Capacitive Touch
Panels
Projected capacitive touch solutions engineered for industrial reliability — glove-compatible, sealed to IP67, and built to your exact OEM dimensions and interface protocol.
Construction
Engineered Layer by Layer
Every capacitive touch panel is a precision optical stack — each layer critical to sensitivity, clarity, durability, and environmental sealing.
L-01
Cover Lens
Tempered Glass / PET / PC
L-02
AF / AG Coating
Anti-Fingerprint / Anti-Glare
L-03
ITO Sensor — X Axis
Indium Tin Oxide Trace Layer
L-04
Optical Adhesive
OCA Bonding Layer
L-05
ITO Sensor — Y Axis
Complementary Axis Traces
L-06
Shielding Layer
EMI / ESD Ground Plane
L-07
FPC / Tail
I²C / SPI / USB Interface
L-08
Rear Adhesive Mount
Industrial Mounting Interface
Technical Parameters
Optical & Touch Specs
Standard performance parameters for our PCAP touch panel assemblies. All values configurable to your application requirements.
Materials & Configuration
Built to Your Substrate
Cover lens material, sensor stack, interface protocol, and surface treatment selected to match your environment and display integration.
Cover Lens Materials
Sensor Technologies
Interface Protocols
Surface Treatments
Capabilities
Feature & Build Variants
Touch mode, optics, sealing, shielding, and display integration options — configured precisely to your operating environment and OEM spec.
OEM Manufacturing
Built for Serious Production
OEM Specification Build
Every panel designed to your exact dimensions, sensor layout, and interface protocol — no off-the-shelf compromises.
Prototype to Volume
Quick-turn engineering samples for firmware and mechanical validation, scaling to full OEM production runs.
Controller Integration
FPC tail routing, controller IC selection, and I²C / SPI / USB protocol support handled end-to-end.
Tested & Certified Output
Touch sensitivity, linearity, noise immunity, and ESD robustness verified on every batch before dispatch.
Applications
Industries Served
Manufactured for touch-intensive industrial, medical, and public-access applications where optical clarity and environmental sealing are critical.
Ready to Build Your
Touch Solution?
Share your panel dimensions, touch requirements, or display integration spec — our team will respond with a detailed manufacturing quote.
