Retroreflective
Stickers & Marking
Engineer Grade to Diamond Grade retroreflective stickers and sign plates — manufactured on aluminium, polyester, and polycarbonate substrates, with screen-print and digital UV legend options, in white, yellow, amber, red, green, fluorescent, and custom colours — for road safety signage, vehicle conspicuity marking, hazard chevrons, construction site boundaries, rail markings, and industrial plant safety applications across highway authority, OEM, and fleet supply.
A retroreflective marking sends light directly back to its source — the driver's headlamp.
Standard paints and non-reflective materials scatter light in all directions; at 150 metres in darkness, a vehicle doing 80 km/h needs retroreflective markings on the road environment and on other vehicles to react in time. Retroreflectivity is not a premium finish — it is a legally required performance specification on highway signs in every jurisdiction that has adopted IRC:67, ASTM D4956, or EN 12899-1 standards. The correct grade of film at the correct RA value is what makes a sign visible, not just present.
Film grade determines performance class — and failure mode when underspecified.
Engineer Grade glass-bead film is appropriate for low-speed roads and site signage up to seven years. High-Intensity prismatic film meets the RA floor for national road regulatory and warning signs. Diamond Grade sealed-lens prismatic is the specification required for motorway and high-speed road environments where signs must remain above minimum RA thresholds for ten to twelve years. Substituting a lower grade to reduce initial cost results in below-standard retroreflectivity before the design service life expires — a liability risk for any road authority or OEM.
Vehicle conspicuity marking is compulsory — and the grade is specified by regulation.
CMVR Rule 104 and AIS-008 mandate retroreflective conspicuity tape on heavy commercial vehicles in India; UN ECE R104 sets the same requirement in 54 countries. The specified tape must meet minimum RA and colour values at defined observation and entrance angles — not any reflective product that appears visually bright. We manufacture vehicle conspicuity marking tape and rear chevron boards to the exact grade, colour, and dimensional requirements of the applicable regulation for OEM fitment and fleet retrofit programmes.
Retroreflective Grades
Choose the Right Grade
Engineer Grade for low-speed and site applications, High-Intensity for national road signage and vehicle marking, Diamond Grade for motorway, high-speed, and long-life critical safety applications. Tell us the application, road speed, and service life requirement — we'll specify the correct grade.
| Property | Engineer Grade | High-Intensity Grade | Diamond Grade (Premium) |
|---|---|---|---|
| Best For | Low-speed roads, site signage, general warning | National roads, regulatory signs, vehicle marking | Motorways, high-speed roads, critical safety marking |
| Grade (ASTM D4956) | Type I — Engineer Grade | Type II / III — High-Intensity | Type IV — Diamond Grade |
| Min RA (White, cd/lx/m²) | 70 cd/lx/m² | 250 cd/lx/m² | 800 cd/lx/m² |
| Outdoor Life | Up to 7 years | Up to 10 years | Up to 12 years |
| Film Technology | Glass bead retroreflective | Micro-prismatic cube-corner | Sealed-lens diamond prismatic |
| Typical Application | Site signs, asset marking, general warning labels | Road signs, vehicle chevrons, construction zone | Highway signs, motorway, emergency vehicle marking |
Construction
Engineered Layer by Layer
Eight material and processing layers — from the silicone-coated liner through pressure-sensitive adhesive, aluminium or polyester substrate, prismatic cell array, colour filter, retroreflective face film, printed legend, and UV overlaminate — combine into a sticker construction that retroreflects accurately, bonds permanently, and survives its rated outdoor service life in road and industrial environments.
L-01
Protective Overlaminate
UV-Stabilised Clear Coat — Gloss or Matte
L-02
Printed Graphic / Legend
Screen or Digital Print on Retroreflective Face
L-03
Retroreflective Micro-Prismatic Face
Type III / IV Engineer- or High-Intensity Grade
L-04
Colour Filter Layer
Red / Amber / Yellow / White / Green / Blue
L-05
Prismatic Cell Array
Cube-Corner Microprism Geometry — 50–80 µm Cell
L-06
Aluminium or Polyester Face
0.3 mm Al Sheet or 75–125 µm PET Substrate
L-07
Pressure-Sensitive Adhesive
Permanent High-Tack / Removable / Structural
L-08
Liner Release Coat
Silicone-Coated PET or Paper Liner
Technical Parameters
Film & Performance Specs
Standard performance parameters across our retroreflective sticker and sign plate range. All values grade- and substrate-dependent — specify your application environment and service life requirement for confirmation.
Materials & Configuration
Built to Your Safety Specification
Retroreflective grade, substrate, print type, colour, adhesive system, cut format, and supply format — every variable configured precisely to your application surface, road or industrial environment, and regulatory requirement.
Retroreflective Film Grades
Substrate & Backing Options
Print & Marking Options
Cut & Supply Formats
Capabilities
Feature & Build Variants
Retroreflective grade, film colour, substrate, print method, adhesive type, cut format, and supply method — every variable configured to your road, industrial, or OEM application requirement.
Production Capability
Built for Serious Production
Retroreflectivity That Meets the Standard — Every Time
Diamond Grade prismatic retroreflective film delivers measured RA values from 250 to 1000 cd/lx/m² depending on colour and observation angle — verified against ASTM D4956, IS 15058, and IRC:67 retroreflectivity test specifications. Each production batch inspected against a calibrated retroreflectometer before release; certification data available on request for highway authority and OEM procurement requirements.
Twelve-Year Outdoor Life on Aluminium Sign Plate
Diamond-grade prismatic film on 0.3 mm or 1.0 mm hot-dip aluminium substrate, sealed with UV-stable overlaminate, rated to twelve years outdoor service life on road-facing vertical surfaces in tropical and arid climates — ASTM D4956 Table 1 Type IV performance class. Colour shift, delamination, and retroreflectivity loss all tested to the same standard. Specified for national highway sign replacement where minimum ten-year service life is contractually required.
Screen-Print and Digital UV Legend on Retroreflective Face
Legends, pictograms, arrows, and full-colour regulatory graphics applied to retroreflective face stock by screen-printing or digital UV flatbed print. Screen-print inks formulated for outdoor UV and moisture resistance on retroreflective surfaces — not standard sign inks that obscure retroreflectivity. Digital UV print available for short-run, variable-data, and multi-colour designs that exceed screen-print colour count or minimum order thresholds.
Volume Supply — Road Authorities, OEM, and Fleet
Production capacity for road authority sign replacement programmes, vehicle manufacturer conspicuity marking kits, and fleet operator retroreflective sticker supply. Roll stock and pre-cut blanks dispatched on scheduled release against blanket purchase orders. Part-number continuity, colour consistency, and retroreflectivity grade matched across reorders — critical for fleet operators who cannot mix grades or colour batches on a single vehicle.
Applications
Surfaces & Sectors Served
Wherever retroreflective marking is required to keep people and assets visible in low-light and night-time conditions — from national highway signage and commercial fleet conspicuity through construction site boundaries, industrial plant safety, and rail marking.
Reflective & Safety Range
Related Products
Reflective Safety Labels
Retroreflective adhesive labels for equipment, machinery, and site asset identification — in standard and custom shapes, with screen-print or UV-print legend.
Reflective Signage
Retroreflective sign plates on aluminium substrate for road, site, and industrial environments — Engineer through Diamond Grade, supplied blank or with printed legend.
Road Safety Signs
IRC:67-compliant road safety and regulatory signs — retroreflective sheeting on aluminium backing with screen-printed legend, supplied to highway authority specifications.
Every Surface Marked.
Every Standard Met.
Share your application surface, road speed or environment, required retroreflective grade, and service life — we'll confirm the correct film specification and supply a detailed manufacturing quote.
