Custom Barcode
& QR Code Labels
Precision-printed barcode and QR code labels across every major symbology — Code 128, Code 39, EAN-13, QR, Data Matrix, GS1 — on silver polyester, white polyester, or polycarbonate substrates, ISO scan-grade verified, engineered for automated scanning, supply-chain compliance, and product traceability from prototype to production volume.
The right symbology for your scanning environment.
Linear barcodes for standard laser scanners, QR codes for mobile and web workflows, Data Matrix for miniature labels on PCBs and medical devices — we recommend the correct symbology for your reader, environment, and data payload before a single label is printed.
Grade A from the first label to the last.
Every barcode and 2D code on every production roll is verified to ISO 15416 (linear) or ISO 15415 (2D) Grade A at the point of manufacture. Scan failures are eliminated before the product leaves the factory, not discovered at goods-in.
One label. Every reader. Any format.
Linear barcode, QR or Data Matrix, human-readable interpretation, and serial number co-exist on a single label. Automated lines, handheld readers, fixed cameras, and consumer phones all decode the same label without adaptation.
Symbology Selection
Choose the Right Code Format
Linear barcodes for high-speed conveyor scanning, QR codes for mobile-first workflows and URL encoding, Data Matrix for miniature labels with maximum data density. Not sure which fits your workflow? Share your scanner model and data payload — we'll specify the right symbology.
| Property | Linear Barcode | QR Code | Data Matrix |
|---|---|---|---|
| Dimensions | 1D — variable width bars | 2D — square matrix | 2D — square / rectangular |
| Data Capacity | Low — 20–80 chars typical | High — up to 4,296 chars | High — up to 2,335 chars |
| Min. Print Size | ~8 mm height required | ~5 × 5 mm feasible | ~2.5 × 2.5 mm feasible |
| Scanner Required | Standard laser / CCD | Camera / 2D imager / phone | 2D imager / industrial |
| Error Correction | Check digit only | Up to 30 % data recovery | Up to 25 % data recovery |
| Common Standards | GS1-128, HIBC, Code 39 | ISO 18004 / GS1 QR | GS1 ECC200 / UDI / IUID |
Construction
Engineered Layer by Layer
Eight processing and material layers — from substrate selection through barcode encoding and scan verification — combine to deliver a label that prints at the required module size, adheres permanently to your surface, and scans reliably throughout the product's service life.
L-01
Printed Barcode / QR Legend
Code 128 / QR / Data Matrix / GS1
L-02
Protective Overlaminate
Gloss / Matte / Anti-Scratch Coat
L-03
Face Material
Polyester / Polycarbonate / Paper
L-04
Tie Coat / Primer
Adhesion Promotion Layer
L-05
Pressure-Sensitive Adhesive
Permanent / Tamper / Freezer Grade
L-06
Liner Release Coat
Silicone Coated PET / Paper Liner
L-07
VOID Security Pattern
Tamper-Evident Transfer (Optional)
L-08
Variable Data Layer
GS1 / UID / Sequential Encoding
Technical Parameters
Material & Print Specs
Standard performance parameters for our barcode and QR label range. All values configurable to your scanning environment, substrate requirement, and regulatory compliance specification.
Materials & Configuration
Built to Your Scanning Spec
Substrate, symbology, adhesive grade, and overlaminate configured precisely to your scanner type, application environment, and supply-chain or regulatory compliance requirement.
Face Materials
Barcode Symbologies
2D Codes
Adhesive & Finish
Capabilities
Feature & Build Variants
Symbology, substrate, adhesive grade, supply format, and finish — every variable configured to your scanning infrastructure, production workflow, and compliance requirement.
OEM Manufacturing
Built for Serious Production
Every Symbology, One Supplier
From the simplest Code 39 linear barcode to GS1-128, Data Matrix ECC200, and QR codes encoding URLs, UIDs, or full GS1 application identifier strings — all produced and verified in-house against the relevant ISO scan-grade standard.
Grade A Scan Verification
All barcodes and 2D codes verified to ISO 15416 (linear) and ISO 15415 (2D) Grade A on production. No label ships with a barcode that fails to decode reliably in any standard scanner or mobile device.
Combined Data on One Label
Linear barcode, QR or Data Matrix, human-readable text, serial number, and logo can all co-exist on a single label — giving automated scanners, handheld readers, and human operators identical information from a single source.
GS1 & Regulatory Compliant
GS1-128, HIBC, and UDI-compliant label structures available with correct application identifier formatting, check digits, and human-readable interpretation lines — ready for pharmaceutical, medical device, and food supply-chain submissions.
Applications
Industries Served
Wherever products, components, or assets need a scannable, verifiable, permanent identity — from high-speed automated conveyor lines and pharmaceutical GS1 compliance to miniature PCB traceability and retail point-of-sale.
Every Label Scannable.
Every Code Grade A.
Share your symbology requirement, label dimensions, data payload, and scanning environment — we'll come back with a substrate recommendation and a detailed manufacturing quote.
